Romex®
Romex® 12/2NM-WGX250 Building Wire, 12 AWG Wire, 2-Conductor, 250 ft L, Copper Conductor, PVC Insulation, Nylon Sheath
- Bend Radius: 1 in
- Conductor Insulation: PVC
- Conductor Material: Copper
- Current Rating: 20 A
- Length: 250
- Model #: 12/2NM-WGX250
- UPC #: 032886163050
- SKU: 8153827
Your shopping list will be used for pickup in-store
Availability may vary by store. Please contact your dealer.
Product Details
Romex® Building Wire, NM-B, Wire Size: 12 AWG, 250 ft L, Number of Conductors: 2, Strands per Conductor: 1, Conductor Material: Copper, Conductor Insulation: PVC, Stranded/Solid: Solid, Sheath Material: Nylon, Sheath Color: Yellow, Sheath Diameter: 0.422 in, 600 V, 20 A, Resistance: 1.662 Ohm, Bend Radius: 1 in, Operating Temperature: 90 deg CKey Features
- Copper conductors are annealed copper
- Stranded conductors are compressed stranded
- Romex® Brand SIMpull® NM-B cable is designed for easier pulling, resulting in easier installation
- Made in America
Item Specifications
| Bend Radius | 1 in |
|---|---|
| Conductor Insulation | PVC |
| Conductor Material | Copper |
| Current Rating | 20 A |
| Length | 250 |
| Number of Conductors | 2 |
| Operating Temperature | 90 deg C |
| Resistance | 1.662 Ohm |
| Sheath Color | Yellow |
|---|---|
| Sheath Diameter | 0.422 in |
| Sheath Material | Nylon |
| Stranded/Solid | Solid |
| Strands per Conductor | 1 |
| Type | NM-B |
| Voltage Rating | 600 V |
| Wire Size | 12 AWG |
MORE DETAILS:
- Application: For both exposed and concealed work in normally dry locations, primarily use in residential wiring as branch circuits for outlets, switches and other loads
